PUMP ONLY: Muscle up your engine cooling system with the Davies Craig EWP®150 alloy Electric Water Pump. Like all EWPs, this advanced unit is designed for remote mounting in the engine bay to satisfy those higher horsepower, turbocharged, supercharged and ‘worked’ engines which develop excessive heat & intercooler applications. The compact EWP®150 alloy unit is manufactured with -AN16 ORB internal inlet and outlet fittings for neat, tight screw-in fitting applications. This rugged alloy hi-flow electric water pump is designed to complement or replace the engine’s existing mechanical water pump. This essential performance accessory increases power to your vehicle’s drive wheels and improves coolant temperature control.
Operating voltage 3V DC to 15V DC Maximum current 10A @ 13V Flow rate (max) 162L/min (42.8 US gal/min) @ 13V DC Operating temp. -40° to 120°C (-40° to 248°F) Pump design
Clockwise centrifugal with volute chamber
Pump weight 1,170 grams (2.6 lb) Pump material Aluminium (Powder Coated) Burst pressure 500 kPa (72.5 psi) Seal Ceramic face seal
Self Priming
No, none of our pumps are self-priming
Fits hose size
35mm to 51mm (1.38” to 2”)
Push-On fitting Size
EWP Inlet & Outlet 38mm
with 3mm Sleeve (#8510) 44mm
with 6mm Sleeve (#8511) 51mm
Internal Fitting -Inlet & Outlet: -16AN ORB
